Product Overview

- TAIUNI Pick and Place Mechanism is an integrated automated solution for transferring pre-filled medicine bottles from a production conveyor into cardboard cartons.

- The system combines a conveyor belt, a positioning/alignment mechanism, a 4-axis pick-and-place robot with sponge suction cups, sensors, touchscreen control, and a CE-compliant system control cabinet.

- Designed and optimized for cost-efficiency and production throughput with in-line quality testing during manufacturing.

Product Features

- Conveyor belt to receive bottles from upstream processes and feed the alignment stage.

- Positioning mechanism that organizes bottles into a precise 4-row by 5-column formation using a pusher cylinder and multiple detection sensors for reliable robot picking.

- 4-axis robot pick-and-place unit equipped with sponge suction cups and detection sensors for gentle, accurate handling.

- Intuitive touchscreen HMI for easy configuration of speed, timing, and positioning parameters.

- System control cabinet housing PLC, switching power supply, servo drivers, relays and terminals; components comply with CE standards.

- Low noise operation (below 70 dB).

Product Value

- Increases packaging throughput and consistency by automating bottle sorting and carton loading.

- Improves product handling quality and reduces breakage/contamination risk via gentle suction cups and precise alignment.

- Reduces labor costs and repetitive manual work while enabling faster changeovers through touchscreen controls.

- Enhances overall quality control and reliability by using detection sensors and rigorous in-house testing during manufacture.

Product Advantages

- Modular, end-to-end design integrates conveyor, alignment and robot stages for smooth material flow.

- High precision and gentle handling from the 4-axis robot and sponge suction cups suitable for fragile containers.

- Robust control architecture (PLC + servo drivers) with CE-compliant components for industrial reliability.

- User-friendly touchscreen HMI for quick setup and adjustments without specialist intervention.

- Backed by TAIUNI’s technical team, quality testing processes and customer service network for installation and after-sales support.

Application Scenarios

- Pharmaceutical packaging lines for filling and cartoning medicine bottles.

- Cosmetic or small-bottle consumer goods packaging where gentle, precise handling is required.

- Food and beverage plants handling small containers that need automated grouping and carton loading.

- Integration with upstream feeders (vibratory, bowl, step or centrifugal feeders) and downstream carton sealing/labeling stations.

- Any automated assembly or packaging line that requires fast, repeatable pick-and-place of small cylindrical containers.
